GEPRC SPEEDX2 1002 18000KV Brushless Motor

Overview

The GEPRC SPEEDX2 1002 18000KV is a lightweight brushless motor designed for 1S micro FPV drones, offering an excellent balance of power, efficiency, and flight time. Engineered for Tiny Whoops, toothpick builds, and lightweight freestyle quads, it delivers smooth throttle response and precise control while maintaining exceptional efficiency.

Optimised for 1S LiPo batteries, the 18000KV version provides a more balanced power curve than its higher KV counterpart, making it ideal for pilots who prefer longer flight times, smoother throttle resolution, and improved efficiency without sacrificing performance. Whether you're flying indoors or outdoors, the motor offers dependable power and responsive handling for a wide range of micro FPV applications.

Constructed with a precision CNC-machined aluminium bell finished in titanium blue, the motor combines durability with an ultra-lightweight design. Premium 415ZZ high-speed bearings ensure smooth, low-vibration operation, while the compact 1002 stator delivers consistent torque and reliable performance throughout the flight.

Features

• High-efficiency 18000KV brushless motor designed for 1S LiPo FPV drones.

• Excellent balance of power, efficiency, and flight time.

• Smooth throttle response for freestyle, cruising, and racing.

• Precision CNC-machined aluminium bell with titanium blue finish.

• Premium 415ZZ bearings for reliable, low-vibration performance.

• Lightweight design improves agility and overall flight characteristics.

• Ideal for Tiny Whoops, toothpick builds, and 1.6"–2" micro FPV drones.

Specifications

• Model: GEPRC SPEEDX2 1002 18000KV

• KV Rating: 18000KV

• Configuration: 9N12P

• Stator Diameter: 10mm

• Stator Height: 2mm

• Shaft Diameter: 1.5mm

• Motor Dimensions: Ø13.69 × 7.75mm

• Lead Wires: 28AWG, 36mm

• Recommended Battery: 1S LiPo

• Maximum Power: 42.3W

• Maximum Current: 11.4A

• Recommended ESC: 12A

• Mounting Pattern: 6.6 × 6.6mm (M1.4)

• Weight: 2.5g (including 50mm wire)

• Colour: Titanium Blue

Recommended Applications

Suitable for:

• Tiny Whoop FPV drones

• 1.6-inch micro FPV drones

• 2-inch lightweight FPV drones

• Toothpick builds

• Indoor and outdoor freestyle flying

Package Includes

• 1 × GEPRC SPEEDX2 1002 18000KV Brushless Motor

• 6 × M1.4 × 3mm Mounting Screws
