GEPRC SPEEDX2 1003 14800KV Motor (4pcs)

Overview

The GEPRC SPEEDX2 1003 14800KV is a premium ultra-lightweight brushless motor developed for 1.6 to 2-inch FPV drones where fast throttle response, efficiency, and low weight are essential. Designed for high-performance micro freestyle and racing builds, this motor combines advanced materials with precision engineering to deliver smooth, reliable power.

Featuring a high-efficiency magnetic circuit, N52H high-strength magnets, and a Kawasaki 1200 stator, the motor offers excellent torque, rapid spool-up, and precise throttle control. The optimized magnetic design helps maximize efficiency while maintaining stable performance throughout the flight envelope.

The one-piece CNC-machined 7075 aircraft-grade aluminium bell keeps the motor exceptionally lightweight at only 3.2g, while providing outstanding durability and impact resistance. A large hollow bell design improves airflow around the stator, reducing operating temperatures and increasing overall efficiency during demanding flights.

High-quality NMB precision bearings ensure exceptionally smooth operation with minimal vibration, making the SPEEDX2 1003 an excellent choice for pilots looking for responsive handling and reliable long-term performance.

Features

• High-performance 14800KV motor designed for lightweight 1.6"–2" FPV drones.

• Optimized magnetic circuit with premium Kawasaki 1200 stator for fast throttle response.

• High-strength N52H magnets provide excellent efficiency and torque.

• Precision NMB bearings deliver smooth, vibration-free operation.

• CNC-machined 7075 aircraft-grade aluminium unibell construction.

• Lightweight hollow bell design improves cooling and reduces copper losses.

• Matte black finish with precision-machined polished edges.

• Ideal for micro freestyle, racing and toothpick FPV builds.

Specifications

• Model: GEPRC SPEEDX2 1003 14800KV

• KV Rating: 14800KV

• Maximum Power: 78.4W

• Peak Current: 10.6A

• Internal Resistance: 95mΩ

• Magnet Type: N52H

• Bearing Type: NMB

• Stator Configuration: 9N12P

• Motor Dimensions: Ø13.6 × 8.7mm

• Shaft Diameter: 1.5mm

• Shaft Length: 3mm

• Mounting Pattern: 3 × Ø6.6mm

• Wire Length: 50mm (30AWG)

• Recommended ESC: 12–20A

• Recommended Battery: 2S LiPo

• Winding: Multi-strand copper

• Weight: 3.2 ± 0.2g (including wires)

Recommended Applications

Suitable for:

• 1.6-inch FPV drones

• 2-inch freestyle drones

• Toothpick FPV builds

• Lightweight racing quadcopters

• Indoor and outdoor micro FPV aircraft

Package Includes

• 1 × GEPRC SPEEDX2 1003 14800KV Brushless Motor

• 6 × M1.4 × 4mm Mounting Screws
